our most powerful electrical CAD software ever!

WSCAD SUITE X PLUS comes with modern technologies like augmented reality, multi-threading and automation and includes a broad set of new features, significantly improved quality and it can be customised to your specific needs. This is exactly the electrical CAD software that you have been waiting for. There is a lot to love – especially the price!

Test the Demoversion NOW!

Additional benefits of the new WSCAD SUITE X PLUS

Lots of interfaces
  • SIEMENS TIA Portal V1.0 and V1.1 – to easily configure PLC assemblies
  • PHOENIX CONTACT PROJECT complete offers support when configuring or labelling terminal strips including multi-level terminals and components
  • Manufacturing machines (drilling, milling, cable assembly and harnessing) from nVent/Steinhauer, Komax, Rittal/Kiesling as well as just in time delivery of preconfigured cable bundles from CadCabel
Optimised for building automation
  • Automatic generation of electrical schematics while assigning existing data points to the controllers. Saves huge amounts of time and substantially increases quality
  • New data point key plugin BKS_13 for building automation, especially when working with FRAPORT and TROX
  • Extension of data point key plugin BKS_Open, in order to use functional texts and part information for the automatic generation of the data point keys
Enhanced usability
  • Data export can be configured as needed, by using path variables
  • Wire designation is super flexible and can be customized
  • Save even more time by comfortably using rotation variations
  • Optimised structure of the menu
Interdisciplinary Engineering
  • Cables are consistently managed across all engineering disciplines: building automation, electrical installation, electrical schematics
  • Changes made in one place are being promoted through the complete project, so the user doesn’t have to think about it

More technical information about the new WSCAD SUITE X PLUS can be found here

Lightning fast

We pay particular attention to speed and performance, because speed is one of the top three most important features for Electrical CAD users. Projects with more than 1,000 pages can be opened at lightning speed. A PLC is created in no time at all, terminal management is super easy and the complete documentation of your project is ready up to 10 times faster than in previous versions. As a WSCAD customer, you just finish your work faster.


We believe in automating processes and routine tasks, so engineers and designers can make better use of their valuable time. Numerous design templates (macros) are the first step of automation. By creating a company-wide uniform standard, they save time and raise the quality of your designs too. Schematics can then be generated automatically from these templates (macros) at the push of a button. This saves days and weeks of valuable work. The complete creation of schematics can be automated by using product configurators with WSCAD SUITE. Engineering time is reduced from weeks to just a few minutes. Find out how companies like Bruckmann Steuerungstechnik or Caterpillar have implemented this with WSCAD SUITE.

Augmented Reality App

A unique highlight of the WSCAD SUITE X PLUS are the two augmented reality apps. Both apps are free of charge in the Apple App Store and on Google Play.

Cabinet AR App

With the Cabinet AR app maintenance personnel and service technicians can scan field devices and components from a control cabinet. They then have immediate access to the actual schematics, including BMK, 3D views of the component, part data and original data sheets from the manufacturer. The availability of a component can also be determined in real time. In production, workers can use the Cabinet AR app to mark wired connections using a smart wiring checklist and thus save the current status. An evaluation always ensures that nothing has been forgotten.

Building AR App

We have developed an augmented reality app to help building designers scan buildings in no time. This becomes necessary, if changes are made to an existing building and the documentation is not available or if it contains many errors. With the Building AR app you can scan entire rooms including doors and windows and save them as a DXF file. The DXF file can then be further edited in the WSCAD SUITE X PLUS. Scanning rooms or even an entire building is easy.

Usability, functionality, fair price

Usability is our top priority, because 55% of all Electrical CAD users claim that ease of use is by far their most important feature. And although the WSCAD SUITE is easy to use, it provides a very wide range of functions. You can start small and expand the functionality at any time via Add-On modules. Electrical schematics, control cabinets, piping and instrumentation diagrams (P&ID), fluid power, building automation as well as the entire electrical installation – everything is implemented consistently on one platform. This saves a lot of time when implementing changes and it helps you avoid mistakes.

But good software doesn’t have to be expensive: compared to other solutions on the market WSCAD SUITE X PLUS is significantly cheaper than comparable products from our competitors, usually by 40%. And you will find that this cost advantage also applies to the annual recurring maintenance costs. See for yourself!

Modular, scalable and flexible: purchase or subscription (rent)

Whether you need additional functions or more licenses, the WSCAD solution is modular and scalable. It grows with the increasing demand, without data breaks. To immediately enhance your application, simply activate your product key and you are done.

You can buy or rent WSCAD SUITE X PLUS. The short-term rent covers temporary needs or peak loads. While the long-term rental (12 months or longer) helps you use WSCAD SUITE cost-effectively without burdening your capital investment.

The software license is available for a single user (node ​​locked) or as a multi-user network license (floating). Network licenses offer additional investment protection: you can use the borrow-function to temporarily borrow network licenses. Should you lose your laptop e.g. lost on a trip, the license will automatically jump back to the server after the borrowing period expires. The license is not lost and your investment remains protected.

SWITCH your old electrical CAD software!

Trade in your old Electrical CAD software and switch to the modern WSCAD SUITE X PLUS. No matter whether your old Electrical CAD software is still in maintenance or not, whether you use it daily or rarely – you can now trade it in when you switch to the multi-award-winning WSCAD SUITE solution.

Good for you and for the world’s progress in electrical engineering.

Give us a call to get your personalised offer:
United Kingdom +44 (0) 203 966 2446
France +49 (0) 8131 3627-373
Eastern Europe +49 (0) 173 4263 330
Germany +49 (0) 8131 3627-98
Rest of the world +49 (0) 8131 3627-365

Or just send us an e-mail:

Download the information brochure as PDF file.
