WSCAD’s partnership with Weidmüller

A reliable partnership
Outstanding projects require outstanding tools. The long-standing and trusting cooperation between Electrix and Weidmüller is a guarantee for future-oriented products and solutions.

Helping to shape the WSCAD data standard

The partnership with Weidmüller has contributed significantly to the definition of the new WSCAD data standard. Together, we have analyzed what information our joint customers need in their article data, both today and in the future. As a result, we have laid the foundation for a new data quality and can now offer you not only Weidmüller article data that meets the highest demands.

A comprehensive, digital product portfolio at

All future articles comply with the newly defined WSCAD data standard and therefore offer you the best possible quality and the necessary data content to be able to use all the functions and interfaces of our Electrix engineering software.
Our article database already contains almost 25,000 Weidmüller article data.
And the number continues to grow!

Our partnership, your advantages as a customer

  • Time saving: Import complete articles in seconds! You save yourself the manual creation which takes 30-60 minutes per article.
  • Rich data content: Our complete article data covers all Electrix functions and interfaces.
  • Highest data quality: The automatic import eliminates errors in article maintenance.

Seamless integration into the WSCAD software

Our cooperation with Weidmüller goes even further. Our ELECTRIX software offers you integrated interfaces to Weidmüller M-Print® PRO and WPC. This allows you to further optimize your work processes:

  • M-Print® PRO: Weidmüller M-Print® PRO
  • Partial automation in cable assembly: Weidmüller cable assembly

Weidmüller is a WSCAD Premium Partner

Weidmüller was recognized as a “Premium Partner” at the SPS 2023 trade fair in Nuremberg – proof of the close and productive cooperation with WSCAD. The Premium Partner logo on identifies data sets in the new format and guarantees the high quality and upto-dateness of the data.
With the Premium Partnership, WSCAD and its partners guarantee that their article data is always up-to-date and available in high quality. Users can select products directly from the application and use them in their plans, including complete article data. This makes electrical engineering faster, simpler and more reliable.
The exemplary integration of Weidmüller articles in not only demonstrates Weidmüller’s high quality standards, but also promotes the shared vision of providing innovative solutions for users.

Dr. Axel Zein (CEO WSCAD GmbH) and Arnd Schepmann (Head of Business Unit Rail Mounted Components, Weidmüller) at the award ceremony at the SPS trade fair in Nuremberg in november 2023.

Ready for the electrical design of the future?

Our partnership with Weidmüller aims to speed up and simplify your projects so that you can focus your time and resources on what really matters.

Ready to optimize your electrical planning and benefit from our partnership with Weidmüller? Contact us today and we’ll show you how to take your projects to the next level!
