Optimize and automate your design process with WSCAD software and Yellax Typical Manager

The creation of electrical schematics can be further automated by using Typical Manager in combination with WSCAD. Typical Manager is used to import large or small lists, to configure machines and/or to manage project data. Hardware configurations can also be created in Typical Manager to organize the existing project I/O automatically or manually.
By generating instead of drawing, copying errors are avoided and uniformity is created, throughout the design process.

Once the project has been compiled in Typical Manager, a WSCAD Project Wizard XML file can be created. This file can then be imported into WSCAD, after the adjustments are automatically made and the data filled in. Pressing the “Generate” button results in the desired uniform electrical circuit diagrams. With the latest, smart Typical Manager functionalities, a very high level of detail can be achieved.

Agenda

WSCAD

  • Creating macros including the required variables
  • Working and configuring in the Project Wizard
  • Exporting data from the Project Wizard via XML
  • Reimport data into WSCAD Project Wizard
  • Generate the circuit diagrams and documentation

Yellax

  • Presentation of the Typical Manager concept
  • Demo of Typical Manager
  • Importing Tags
  • Value sets
  • I/O Management
  • Exporting WSCAD file
  • Report Factory Acceptance Test document
